Disposable IV Filter with Double Decks of PES and Hydrophobic PTFE for Higher Flow Rate

Disposable IV Filter with Double Decks of PES and Hydrophobic PTFE for Higher Flow Rate

Product Details:
Place of Origin:	China
Brand Name:	OEM avaliable
Certification:	ISO9001
Model Number:	XN-GLOL-X
Payment & Shipping Terms:
Minimum Order Quantity:	10000PCS
Price:	$0.50-$0.70 per piece
Packaging Details:	250pcs per pack with label , 8packs per carton or customizable
Delivery Time:	30 days
Payment Terms:	L/C,T/T

Contact Now

Detail Information
Product Description

Detail Information
Product Name:	Single Use IV Filter With Hydrophilic PES 0.2μm And Hydrophobic PTFE 0.2μm	Pore Size:	0.22μm
Filter Media:	PES & PTFE	Filter Housing:	ABS
Stop Liquid Height:	≥1.5Meter	Inlet/Outlet Connections:	Infusion Tube
Assembly Mode:	Heat Melting Or Ultrasonic Welding	Sterilization:	Non-sterile/EOS
Type:	X, Disposable	Advantage:	Automatic Liquid Stop
Color:	Natural, Can Make Lightproof Orange Color
Highlight:	IV Filter , 0.22μm 0.2μm , infusion filter

Product Description

0.2 Micron IV Filter with Double PES Membrane and Higher Flow Rate (Non-sterile)

Single Use IV Filter With Hydrophilic PES 0.22μm and Hydrophobic PTFE 0.2μm (Non-sterile)

This single in-line IV filter is designed for intravenous filtration, effectively removing particles larger than 0.2μm from liquids to ensure drug purity and biological sample safety. It eliminates potentially harmful particles that could compromise product quality, delivering consistently high-purity liquid medications and biological samples.

XINNA's single-use IV filters feature premium materials: double layers of PES membrane for liquid filtration and PTFE membrane for air venting. These materials offer excellent chemical compatibility, resisting corrosion from various chemicals and solvents. They also maintain stable performance in high-temperature environments.

Key Features

Standard luer inlet/outlet for easy connection to IV tubing sets
Precision filtration of fine particles (0.2μm)
High particle retention efficiency
Automatic air venting and air-stop functionality
Reduces risk of phlebitis and infusion pain

Technical Specifications

Dimensions	60 × 29.5 × 0.95mm (including inlet/outlet connectors)
Weight	8.2-8.8g
Filtration area	10.5 cm²
Venting area	1.72 cm²
Venting air flow rate	25ml/min @ 5kpa
Max burst pressure	360kpa (52.5psi)
Operating temperature	5-40℃
Storage temperature	0-50℃
Min water bubble point	0.2μm ≥ 360kpa
Min water flow rate	0.2μm ≥ 200ml/10min @ 10kpa
Sterilization method	Ethylene Oxide (Max 60℃)

Applications

Medical infusion sets
Biomedical and pharmaceutical applications
Laboratory use
